Replacement Hispacold Compressor(2B; Ø 210MM ; 24V) HPC 2B 210; 4050293

Introduction of Hispacold Compressor Clutch 4050293 - Bus Air Conditioner Parts

Bus air conditioner parts 4050293 Hispacold electromagnetic clutch bus ac clutch with 2SPB-16.3mm (210 mm)  2B 210 with beautiful appearance and reliable quality mainly application for Hispacold compressor in bus air conditioning system, HPC 2B 210 Ectromagnetic Clutch is made up of clutch belt pulley assembly and clutch coil. It is specially designed for connecting bus engine and Hispacold air conditioning compressor. If your require bus air conditioner clutch for Hispacold compressor, HPC 2B 210 4050293 is your best choice, by the way, HPC 2B 210W 4050019, HPC 2B 210 4050293, HPC 2B 250 4050021as replacement clutch are common used clutch on Hispacold compressor, Vehicleacparts can provide the Hispacold coatch air conditioner clutch with competitive price,


Bus AC Parts Hispacold Compressor Clutch OEM CODE

CLUTCH BUS A/C COMPRESSOR HISPACOLD (2B ; Ø 210MM ; 24V) ; 4050293
OEM
Catalog number:
Hispacold
4050293
4050336
4050344
Hispacold Compressor Clutch 4050293, 4050336, 4050344

HTAC
HTAC-1377

Hispacold Clutch bus air conditioner parts with coil Description:
- 2x17mm (2B)
Ø 210mm
Internal Ø 165mm
Height: 75mm

Hispacold Clutch Coil - Hispacold Compressor Parts Used For Bus Air Conditioning System
External Ø 164mm
Internal Ø 88mm
Ø 50mm mounting flange
4 mounting screws Ø 9
height 45mm
cone, wedge

Product Description of High quality hispacold A/C compressor magnetic clutch-- BUS A/C PARTS
2SPB-16.3mm (210mm)

rated power:60W
rated voltage:24V
static friction torque:240N.M
Application for Hispacold Air Conditioning compressor
Hispacold clutch 2XB 210mm ,Eco Ice ,Bova & Irizar PB/I6/I8 ,4050293
Compressors for Bock, Valeo, Thermo king, Unicla, Denso, ETC and the compressor inner parts
Electromagnetic clutches for Bock, Valeo, Thermo king, Unicla, Denso, ETC


The Features of HPC 2B 210 4050293 Bus AC Hispacold Compressor Clutch

1.The bus ac Hispacold clutches are easy to install.
2. The bus compressor Hispacold clutch using a wide range.
3. Our Hispacold clutch quality is reliable, within 2 years warranty.
4. It is common model clutch, mainly design used for bus air con Hispacold compressor.
5. Delivery date : 8-10 working days after receiving the deposit
6. Package terms: one set/box and two sets packed into one carton
7. One-stop service and High quality OEM for bus & van and truck air conditioner parts :


The Function of Hispacold Compressor Magnetic Clutch 2B 210 4050293 - Bus Air Con Parts

Hispacold Clutch with Coil, 2B 210 4050293 2G "B" Ø 210, is the common clutch model of Hispacold compressor, this 2B 210 bus air con clutch in the bus air conditioning system is a power transfer device connected between the engine and Hispacold bus ac compressor, mainly apply for driving the Hispacold bus air con compressor operation, to reach for the purpose of bus compartment cooling


Bus A/C Parts Hispacold Compressor Magnetic Clutch HPC 2B 210 4050293 Working Principle

Hispacold Compressor Magnetic Clutch HPC 2B 210 4050293 is controlled by the bus air conditioning switch, thermostat, pressure switch, etc. cut off the power transfer between the bus engine and Hispacold compressor when it is needed

Further more, when the bus air con Hispacold compressor is overloaded in the bus air conditioning system, the bus ac spare part electromagnetic clutch can also play a protective role. Among them, the electromagnetic clutch coil is fixed on the Hispacold compressor shell, the clutch plate hub is connected with the Hispacold compressor main shaft, and the belt pulley clutch is installed on the Hispacold compressor epicranium through the bearing, which can rotate freely, transmit the engine torque to the compressor shaft, and make the compressor shaft rotate.

When the bus air conditioning switch is turned off, the suction force of the electromagnetic coil disappears from the Hispacold compressor. The drive pulley and the clutch plate hub are disengaged under the action of the spring plate, and the Hispacold compressor stops working


Bus a/c Parts - HPC 2B 210 4050293 Hispacold Compressor Clutch Structure and Composition

As bus air conditioner spare parts, HPC 2B 210 4050293 Hispacold Compressor electromagnetic clutch is made up of clutch belt pulley assembly, clutch coil assembly and clutch hub assembly of these three parts.





Bus Air Conditioner Parts - Hispacold compressor clutch Factory

Bus Air conditioning parts 2B 210 4050293 Electromagnetic Clutches for Hispacold Compressor in Bus Air Conditioner OEM cold 4050293 is the main spare part of bus air conditioning system, also belong to bus ac parts, VehicleACParts are professional bus ac compressor magnetic clutch supplier, the clutch mainly used for the various bus & coach air conditioner Hispacold compressor,



Bus Air Conditioner Parts Magnetic Clutch for Hispacold series Compressor

1.HPC 2B 250 Clutch - Bus A/C Parts
2.HPC 2B 210W Compressor Clutch - Bus ac parts



Hispacold Compressor Bus Air Conditioner Clutch Factory

As bus ac part clutch factory, VehicleACParts are professional bus electromagnetic clutch supplier, the clutch mainly used for the bus air conditioning system, our bus compressor clutches are application for the Bock compressor, Bitzer compressor, Thernoking compressor S616, X426, X430, Hispacold compressor and Valeo compressor, Vehicleacparts provide original new TK bus air conditioner compressor clutch replacement with affordable price for Thermo King and carrier bus ac and refrigeration units after sales service market.


Hispacold clutch,2B 210 mm,BB,24V 4050293 - Bus AC Parts

Model	HPC 2B 210W
The slot model of strap wheel	2B
rated voltage	24V
Minimallnhale-close Voltage	DC20V
Static friction torque	≥240 N.m
Consumed power	≤60W
Allowable Max. Revolution	3800R.P.M
Application compressor	Hispacold
Coil	High temperature copper wire
