PTC High Voltage Electric Bus Defroster Heater
The PTC defroster is constituted by PTC heating unit, with the over temperature alarm and automatic cutting off function, controlled by high voltage relay with higher safety and stronger reliability;
The air outlet of 5KW 600V PTC defroster heater is composed of 2 pieces 120mm and 4 pieces 50mm, totally 6 heating air outlet. The heating air outlet can be controlled to open or close, and the air inlet can also be controlled, while the air inlet and outlet of others PTC defroster radiator heater cannot be controlled.
PTC High Voltage Electric Defroster for Electric Bus Vehicle Introduction
Model: 354-17002
Fan voltage (V): 24V (can be customized)
Fan power (W): 260W (can be customized)
PTC voltage (V): DC600V (can be customized)
PTC heating (Thermal ) power (KW): 5KW (can be customized)
Dimensions (MM): 477*200*384mm (customizable)
Air volume (M³/H): 1200 m³/h
Type: Multi-Function Defroster
Application: New Energy Vehicle, Electric Vehicle, etc.
Partner: BYD,GEELY
Features: Customizable
Installation: Wall Radiator
5KW 600V PTC High Voltage Electric Bus Defroster Features
☆ Integrated design of cold and warm air to achieve defogging and defrosting
☆The centralized control system using CAN communication can realize electric bus vehicle communication
☆ Adopt Double temperature protection, with high temperature protection and alarm function
☆ Using long-life brushless evaporative fan, low noise and longer service life
☆ Customizable PTC Defroster
Optional Function of 5KW PTC High Voltage 600V Electric Bus Defroster
☆ Optional fresh air function, adjustable air outlet function, can meet the level requirements of IP67
☆ Optional air outlet angle adjustment function, which can realize the functions of face blowing, foot blowing and defrosting
☆ With E-MARK certification, it can meet export requirements
High Voltage 5KW 600V Electric City Bus Defroster Advantage
1. It is constituted by PTC heating unit with higher safety;
2. The PTC electrification is controlled by high voltage relay with stronger reliability;
3. The over temperature alarm and automatic cutting off function are adopted;
4. Various high voltage is available and high voltage 600V is the most popular
5KW 600V All-lectric Bus Front Windshield PTC Defroster Application:
The electric PTC defroster is for all new energy electric bus vehicle, such as YUTONG electric bus, GEELY all-electric citybus, BYD new energy electric coach & buses.
Why is the PTC Defroster Radiator Heater is Necessary for New Energy Buses?
With considering the environment, more and more new energy bus & coach vehicle is produced. Then electric PTC front windshield Defroster heater radiator is required to suitable for this new electric bus
Why Choose Electric Bus High Voltage 600V PTC Radiator Defroster?
Low electricity consumption, absolutely silent, easy installation, conform to the trend of energy saving and emission reduction of the times and Electric Bus Front Windshield Multifunction PTC Defrosters Heater is environment-friendly;
How to Use Bus Front Windshield Multifunction PTC Defrosters Heater
Electric Bus PTC defrosters heater for the wiper parking area front windshield, used for defrosters safely defrost the area at the bottom of the front windshield in the wiper parking area. It is cost effective and easy to install, these new Multifunction PTC electric defrosters bond directly to the window to match the heating performance of factory installed defrosters, melting snow and ice in minutes, quickly realize the defogging and defrosting of electric buses, contact infor@vehicleacparts.com the Electric PTC Radiator Defroster Heater will be Your Best and Wisest Choice
The PTC defroster is constituted by PTC heating unit, with the over temperature alarm and automatic cutting off function, controlled by high voltage relay with higher safety and stronger reliability;
Advatage of PTC Defroster
Multi-function, integrated design of cold and warm air
PTC heating unit, CAN Control System
☆ Integrated design of cold and warm air to achieve defogging and defrosting
☆The centralized control system using CAN communication can realize electric bus vehicle communication
