Bus Water Tank Radiator Cooling Spal Axial Fan VA09-BP12/C-27A
SPAL Axial Fan VA09-BP12/C-27A 24V Bus Engine Water Tank Radiator Cooling Fan Introduction
High efficiency, compact construction and superb reliability are the core requirements for modern bus condensor fan. Bus A/C Parts VA09-BP12/C-27A brused axial fan has a longer service time and warranty period, it is mainly design for various bus engine water tank radiator cooling, and widely used in Chinese Yutong citybus air conditioning system for Vehicle Water Tank Cooling, VA09BP12C27A 24V Axial Fan Cooling Fan is your best choose for vehicle Water Tank Cooling air conditioner such as bus, rv, van, coach buses, citybus, school bus, and so on.
Bus Engine Cooling Electronic fan VA09-BP12/C-27A, 280mm, 120W, 24V, 1450 Air Flow, Suction, Water tank Radiator Fan Original, mainly install on the side of the bus engine radiator, this one is universal radiator cooling fan, max air flow 1450m3/h. Spal cooling air fans are suitable for use in motorsport applications as well as high performance replacement units for road vehicle and kit cars such as bus, school bus, coatch, RV, citybus, travel bus.
Quick Details of Bus Engine Water Tank Radiator Cooling Axial Flow Fan SPAL VA09-BP12/C-27A 24V
Model: Spal Axial Fan VA09-BP12/C-27A
Wind direction: Suction (mounts on the engine side of the radiator)
Max. thickness: 51,1mm
Blades diameter: 280mm
max air flow: 1450m3/h
Number of blades: 10
Blades type: Straight
Direction of rotation: Clockwise, seen on rotor
Wind direction: Suction
Electrical leads: With plug
Power supply : 24V
Input: 4.6 A
Type: Axial Flow Fan
Customized support： OEM
Electric Current Type： DC
Mounting： FREE STANDING
Blade Material： Plastic
Place of Origin： China
Brand Name： Spal
Model Number： VA09-BP12/C-27A
Warranty： 1 Year
After-sales Service Provided: Online support
IP Rating： IP68
Product Name: Bus engine water tank radiator fan
Type: Original bus dedicated high power fan assembly
Weight: 3,5kg
Applicable Industries: cooling radiators and coils, agricultural machinery, off-road, refrigeration equipment, ventilation in 24 volt vehicles, universal use.
Warming Tips: The wind coming out from the fan motor is sucking the air. If you don't know the hair dryer and the suction, please contact customer service info@vehicleacparts.com
Spal VA09-BP12/C-27A Bus Vehicle Water Tank Radiator Cooling Axial Fan Feature:
Low Power Consumption; Super Long Service Life; Maintenance-free; Environment-friendly; Short Circuit Protection; Over-current Protection; Over-temperature Protection; Over-voltage Protection; Under-voltage Protection; Locked-rotor protection.
High Performance Cooling Axial Fans
Waterproof Long Life Motors
Suitable For Motorsport Or Various Road Cars, such as bus & coatch
Universal Fitting
O/E On Caterham & Morgan Cars
Bus Engine Water Tank Radiator Fan specification classification:
12V 120W VA09-BP12/C-27A
24V 120W VA09-BP12/C-27A
Supply Ability of Bus Cooling Axial Fan SPAL VA09-BP12/C-27A Bus A/C Parts
Supply Ability:
30000 Piece/Pieces per Month
Packaging & Delivery of Bus Engine Water Tank Radiator Cooling Axial Fan SPAL VA09-BP12/C-27A
Packaging Details
Neutral package/Color package
Port: Shangai/ Ningbo
Lead Time: Shipped in 10 working days after payment
SPAL VA09-BP12/C-27A Bus Engine Water Tank Radiator Cooling Fan, Bus A/C Parts Supplier - VehicleACParts
VehicleACParts mainly supply bus condensor fan, bus cooling fan, Bus Cooling Axial Condenser Fan, Vehicle Water Tank Cooling fan, this bus vehicle cooling fan that our business deal widely used on Eiropean, American, Japanese, Korean, Chinese buses and trucks! Our water pump have good quality and competitive price!!!
The Axial Flow bus air conditioner water tank cooling fan VA09-BP12/C-27A is for all kind of bus vehicle brand, such as Mercedes bus, Scania bus, Man buses, Volvo middel bus, Jelcz small bus, Autosan school bus, Solaris city bus, Neoplan minibus, YUTONG bus, GEELY citybus, BYD coach & buses. This bus engine water tank radiator fan adopts Italian imported brush and has a service life of no less than 9000 hours. It has been supporting services with many manufacturers for many years, with an annual output of over 30,000 units, providing one year of free after-sales quality assurance.
Bus Air Conditioner Parts - Citybus Axial Water Tank Cooling Fan, Bus Engine Water Tank Radiator Fan
Bus Cooling Axial Condenser Fan
Watertight throughout entire lifetime
Bus Cooling Fan SPAL VA09-BP12/C-27A Axial Flow Cooling Fan of Bus Engine Water Tank Radiator
