Highly VK-EVS34 R134a DC400-720V

VehicleACParts VK-EVS series All-electric Scroll Bus A/C Compressor Features

1. Light Weight
Compared with the traditional compressors, VehicleACParts VK-EVS 34 series compressors are very light, only 7.5KG, save the power consumption a lot.

2. Reliability
Flexible scroll compression structure; Resistance the liquid refrigerant assault; Smooth operation, low noise and less vibration.

3. Environmental Friendly
Environmentally friendly refrigerant, adopts R134a refrigerant.

4. High efficiency DC frequency conversion technology
Connect the DC high pressure voltage DC150V-420V or DC400V-720V voltage, so customers don’t need to buy a transformer to transform the voltage.

5. Specialized for full electric bus ac or hybrid bus ac
Modulation design for EV/HEV/PHEV/FCEV new enery bus air conditioning system



How to Install VK-EVS series All-electric Bus Air Conditioner Compressor for your New Energy Buses

The electric VK-EVS 34 scroll compressor should be kept in the horizontal direction and the suction port should be kept up (shown as standard installation method, if necessary for other installation methods, both sides must confirm the consultation), in the actual installation of the compressor to allow the direction of tilt within 10 °. Compressor at installation
The direction of the axis is perpendicular to the direction of travel. If the compressor and the grounding function of the metal bracket can not be set to connect the ground, otherwise you need to set up a separate grounding device, can be installed in the foot when the foot shown in the location shown in the figure.



All Electric Bus Air Conditioner Scroll Compressor Supplier - VehicleACParts

VehicleACParts Industry as the leading supplier of bus air conditioners spare parts in China. VK-EVS 34 series full electric bus air conditioner scroll compressor will meet the trend of the times to solve the requirements of new energy customers for all-electric bus compressors of core components, if your all-electric bus air conditioner is GUCHEN, CLING Yutong Brand VK-EVS 34 compressor is original spare parts and your best choose,


Model	VK-EVS34C
Refrigerant	R134a
Displacement ( cc/rev)	34.0
Power type	DC(150V-420V) or DC(400V-720V)
Speed range( rpm)	2000-6000
Communication protocol	CAN2.0B or PWM
Operation Environment Temperature(°C)	-40 ℃~80℃
Oil type	POE,HAF68(150ml)
Max. Cooling Capacity (W)	11000
COP(W/W)	3.0
Compressor length L (mm)	252
Suction diameter D1 (mm)	21.3
Discharge diameter D2 (mm)	15.5
Weight (kg)	7.5
